ICM Controls i3 2010WR User Manual

2
AUTO
SCHEDULE
COOL
FAN
COOL
MODE
PM
OFF
Wed
Thermostat Controls
Left Arrow
(Go Back)
Right Arrow
(Forward)
Down Arrow
Up Arrow
HomeMenu Mode (Heat/Cool) Fan Schedule
AUTO
SCHEDULE
COOL
FAN
COOL
MODE
PM
OFF
Wed
Package Contents/Tools Required
Packageincludes: Thermostat,base,wiringlabels,screws,wallanchors,andInstallation, Operation and Application Guide.
Toolsrequiredforinstallation:Drillwith3/16”bit,hammer,screwdriver
Specifications
ElectricalRating:24VAC(18-30VAC),1ampmaximumperoutputterminal,5ampmaximumtotalload
TemperatureControlRange:45°Fto90°F(7°Cto32°C)Accuracy:±1°F(±0.5°C)
Anti-shortCycle:4minutes(bypassanti-shortcycledelaybyreturningtoOFFmodeandpressingthe
icon).
BacklightOperations:15seconds
SystemCongurations:Allmaybeusedwithheatpump,gas,oil,electric,andairconditioning
•I1010WR:1-stageheat,1-stagecool
•I2010WR:2-stageheat,1-stagecool
•I2020WR:2-stageheat,2-stagecool
•I3020WR:3-stageheat,2-stagecool
