ICM Controls i3 2010WR User Manual

13
Configuration Mode Settings
ThesetupscreensforCongurationModeareasfollows:
1.TemperatureScale(ForC)
ChooseFahrenheitorCelsius.
Pressthe
or toselect.
Press
toadvancetothenextscreen.
CONFIG
2.1stStageTemperatureDifferential(1°Fto5°F)(0.5°Cto2.5°C)
Setthenumberofdegreesbetweenyour“setpoint”temperatureandyour“turnon”temperature.
Pressthe
or tosetdifferentialvalue.
Press
toadvancetothenextscreen.
CONFIG
3. 2ndStageTemperatureDifferential(1°Fto5°F)(0.5°Cto2.5°C)
 Note:Not for 1010W
Setthenumberofdegreesbetweenwhenstage1turnsonandwhenstage2turnson.
Pressthe
or tosetdifferentialvalue.
Press
toadvancetothenextscreen.
CONFIG
4. 3rdStageTemperatureDifferential(1°Fto5°F)(0.5°Cto2.5°C)
 Note:Only for 3020W
Setthenumberofdegreesbetweenwhenstage2turnsonandwhenstage3turnson.
Pressthe
or tosetdifferentialvalue.
Press
toadvancetothenextscreen.
CONFIG

ICM Controls i3 2010WR Specifications

General

Brand	ICM Controls
Model	i3 2010WR
Category	Thermostat
Language	English
