ICM Controls i3 2010WR User Manual

16
11.AuxiliaryDelayON(0-60minutes)
Setthedelaytimeinminutesforauxiliaryheattobelockedoutafteracallforsecondstage.This
extrasavingsfeatureisusedtotemporarilylockoutauxiliaryheatdevices,allowingjustheatpumpto
trytosatisfyheatcall.
Pressthe
or toselect.
Press toadvancetothenextscreen.
CONFIG
HEAT
12.Lockout(0-8°,SLEEP,COOL-HEAT)
Selectthenumberofdegreessettemperaturecanbechangedduringkeypadlockout.SLEEP
settinglocksthermostatonlyduringthesleepperiodtopreventafterhourstampering.COOL-HEAT
lockoutallowsadjustmentofthesettemperaturestothemaximumheatsettemperatureselectedand
minimumcoolsettemperatureselected.
Note:The mode cannot be changed while the thermostat is locked.
Pressthe
or toselect.
Press toadvancetothenextscreen.
CONFIG
10.OutdoorLowerSetpoint(select––todisable)
Appearsonlyforheatpumpwithelectricbackupwithoutdooruppersetpointenabled.
Note:Select lower setpoint for chart on previous page.
Pressthe
or toselecttemperature.
Press toadvancetothenextscreen.
CONFIG
Low
WARNING! : Incorrectsettingscandamagesystemand/orcausepotentiallydangerous
conditions.UsethecodedescribedinCongurationSafetyLock.
Note:Select upper setpoint for chart on previous page. Select to disable.
Pressthe
or toselect.
Press
toadvancetothenextscreen.
9.OutdoorUpperSetpoint(50°Fto25°F,––)(10°Cto-4.0°C,––)
CONFIG
Hi
13.MaximumHeatSetpoint(45°Fto90°F)(7°Cto32°C)
Adjusttocontrolthemaximumheatsettemperatureallowed.
Pressthe
or toselect.
Press toadvancetothenextscreen.
CONFIG
HEAT
