Icom IC-2100H

63
16
SPECIFICATIONS
General
• Frequency coverage : (unit: MHz)
Transmitter
• Modulation system : Variable reactance frequency
• Output power : High 55 W (Thailand version: 10 W
Taiwan version: 25 W
Mid 10 W (approx.)
Low 5 W (approx.)
• Current drain (at 13.8 V DC) :
Transmit Max. power12.0 A (less than 5.5 A for
the Thailand version)
• Spurious emissions : –60 dB (Thailand version: –55 dB)
• Microphone connector : 8-pin modular (600 Ω)
Receiver
• Receive system : Double-conversion
superheterodyne
• Intermediate frequencies : 1st 15.65 MHz
2nd 450 kHz
• Sensitivity (at 12 dB SINAD) : Less than 0.18 µV
• Squelch sensitivity (threshold) : Less than 0.13 µV
• Selectivity : More than 12 kHz/–6 dB
Less than 28 kHz/–60 dB
(6 kHz/–6 dB, 18 kHz/–60 dB; FM narrow mode)
• Spurious response rejection ratio : More than 60 dB
• Audio output power : More than 2.4 W at 10%
(at 13.8 V DC) distortion with an 8 Ω load
• Ext. speaker connector : 2-conductor 3.5 (d) mm (
1
⁄8")
/8 Ω
VERSION
USA
Europe
Australia
Taiwan
Asia
IC-2100-T (Thailand)
TRANSMIT
144–148 MHz
144–146 MHz
144–148 MHz
144–146 MHz
144–148 MHz
144–146 MHz*
RECEIVE
136–174 MHz*
144–146 MHz*
144–148 MHz
144–146 MHz*
136–174 MHz*
144–146 MHz*
*Guaranteed 144–148 MHz only.
• Mode : FM
• No. of memory channels : 113 (including 3 scan edge pairs, 6
scratch pad memories and 1 call)
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
• Frequency stability : ±10 ppm (–10°C to +60°C)
• Power supply requirement : 13.8 V DC ±15%
• Current drain (at 13.8 V DC) :
Receive Standby 0.8 A
Max. audio 1.0 A
• Antenna connector : SO-239 (50 Ω)
• Usable temperature range : –10°C to +60°C; –14°F to +140°F
• Dimensions : 140(W) × 40(H) × 180(D) mm
(projections not included) 5
1
⁄2(W) × 1
9
⁄16(H) × 7
3
⁄32(D) in
• Weight : 1.2 kg; 2 lb 10 oz
