8
1
PANEL DESCRIPTION
■ Microphone keypad
KEY FUNCTION
Toggles between opening and closing the
squelch.
Starts and stops scanning. (p. 37)
Starts and stops priority watch. (p. 42)
Selects high output power. (p. 19)
Selects mid output power. (p. 19)
Selects low output power (p. 19)
Selects –duplex. (p. 21)
Selects + duplex. (p. 21)
Selects simplex. (p. 21)
No primary function.
SECONDARY FUNCTION (after )
No secondary function.
No secondary function.
Turns the one-touch PTT function ON and
OFF. (p. 20)
No secondary function.
No secondary function.
Turns the DTMF memory encoder function
ON. (p. 44)
Turns the subaudible tone encoder ON.
(p. 21)
Turns the pocket beep function ON.
(p. 46)
Turns the tone squelch function ON.
(p. 46)
While being pushed, transmits a 1750 Hz
tone. (p. 22)
After :
Transmit the appropriate
DTMF code or push [0] to
[9], [A] to [D] to transmit the
DTMF memory contents
when the DTMF memory
encoder is activated. (p. 22)
