PANEL DESCRIPTION
■ Function display
q TRANSMIT INDICATOR
➥ Appears while transmitting. (p. 19)
➥ Flashes while transmitting with the one-touch PTT func-
tion. (p.20)
w DUPLEX INDICATORS (p. 21)
“DUP–” or “DUP” appears during semi-duplex operation
(repeater operation).
e TONE INDICATORS
➥ “T” appears while the subaudible tone encoder is in use.
(p. 21)
➥ “T SQL” appears while the tone squelch function is in
use. (p.47)
➥ “T SQLS” appears while the pocket beep function is
in use. (p. 46)
r PRIORITY WATCH INDICATOR (p. 42)
Appears while the priority watch is activated; flashes while
the watch is paused.
t AUTO POWER-OFF INDICATOR (p. 56)
Appears while the auto power-off function is in use.
y BUSY INDICATOR (p. 18)
Appears when a signal is being received or the squelch is
open ([MONI] is pushed).
u FREQUENCY READOUT
Shows the operating frequency, alphanumeric names, set
mode contents, etc.
• Frequency decimal point flashes while scanning. (p. 37)
