4-2 Cloning Software CS-FR5100
4-2-1 Basic Setup of Cloning Software
25
Software installation]
1. Quit all applications when Windows is running.
2. Insert the CD into the appropriate CD drive.
3. Double-click the “Setup.exe” contained in the CD.
4. The “Welcome to the InstallShield Wizard for CS-
FR5100” will appear as below. Click [Next>].
5.The “User Information” will appear as below, then
type your name, your company name and the product
ID number with the following manner. Then click [Next
>].
• ID number: 306401-(6 digit serial number)
• e.g. the serial number on the CD is 000001, enter
“306401-000001” as the ID number.
6. The “Choose Destination Location” will appear as
below. Then click [Next>] to install the software to
the destination folder. (e.g. C:\Program
Files\Icom\CS-FR5100)
• Click [Browse...] to select another destination folder
before clicking [Next >], if desired.
7. After the installation is completed, the “InstallShield
Wizard Complete” will appear as below. Then click
[Finish].
8. Eject the CD.
9. Program group ‘CS-FR5100’ appears in the
‘Programs’ folder of the start menu, and ‘CS-
FR5100’ short cut icon appears on the desktop
screen.
• To uninstall the cloning software, select the “Control
Panel” in the start menu, and click the “Add or
Remove Programs.”
Then, select the program group ‘Icom CS-FR5100’
and click [Remove].
Note 1: Icom distributes cloning software by CD or license. Depending on this, some information here may not
apply as written, e.g. ID number.
Getting started
oThis cloning software is designed to perform data
setting and cloning for the IC-FR5100/IC-FR6100
series VHF/UHF FM REPEATERS.
oHELP WINDOW: CS-FR5100 has a help window to
describe functions and operation.
System requirements
To use this program, the following hardware and
software are required:
PC
• Microsoft
®
Windows
®
2000/XP or Microsoft
®
Windows Vista™ is installed
• With USB port
Other item
Optional OPC-1122U
*
CLONING CABLE (USB type)
NOTE:
To use the OPC-1122U, USB type cloning cable, USB
driver installation is necessary. The driver is supplied
with the OPC-1122U. See the OPC-1122U instruction
manual for the installation details.
*The USB driver, supplied with the OPC-1122U, is not
supported for Microsoft
®
Windows Vista™(64 bit).
