DIGITAL MODE OPERATION (IC-PCR2500 Main band only)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
■ DV mode setting
The IC-PCR2500 can be received in DV* mode and low-
speed data. If the transmit signal is included the GPS data,
position data receiving is available.
*The optional UT-118 is required.
q Click the zSettingx icon on the tool bar to call up the [Set-
ting] screen if it is not displayed.
w Click the zDVx tab to display the DV setting.
e Click
q Click
• [Setting] screen
Check the check box to turn the stanby beep emission ON.
Select the optional unit
power setting.
Select the monitor setting for DV mode.
Check the check box to turn the RX call sign and Message
indication ON, when received.
Select the communication speed be-
tween receiver and PC for slow speed
data communication.
Set the transffer setting for
slow speed data to Com port.
