Iconia B1-A71 - Top View; Bottom View

Hardware Specifications and Configurations 1-7
Top View
Figure 1-3. Top View
Table 1-3. Top View
Bottom View
Figure 1-4. Bottom View
Table 1-4. Bottom View
# Item Description
1 Headset Jack Connects to stereo headphones.
# Item Description
1 Micro-B USB Port
Connects to a computer or power adapter with a USB
cable.
2 Card Slot Cover Insert a micro SD card into the slot under this cover.
1
1 2
