Hardware Specifications and Configurations 1-11
System Board Major Chips
Item Specification
CPU
MT8317T
1.2GHz dual-core Cortex-A9 AP MCU
520 MHz ARM1176 + 260 MHz DSP modem cores MD MCU
Graphics Processor 3D graphics (OpenGLIES 2.0)
LVDS transmitter SN75LVDS83BZQLR
PMU MT6329A
DDR3L DDR3 512MB / 1G
ULPI Phy for USB N/A
Bluetooth Azurewave AW-NH520
Wireless Azurewave AW-NH520
GPS Azurewave AW-NH520
GPS Low-Noise Amplifier BGU7005
TOUCH controller GT927
eMMC 8G / 16G
CAMERA
0.3M Camera – (Chicony 0.3M, OV 7675)
Capture : 15 fps at full resolution - 1600 x 1200
Video recording : 30 fps at HD - 1280 x 720
Thermal Sensor N/A
Audio codec MT8317T (Embedded in CPU)
Audio Amplifier MT6329A (Embedded in PMU)
Echo Cancellation N/A
Battery Charger NCP1851FCCT1G_CSP25
Embedded Controller IC N/A
Compass N/A
Gyro N/A
G-Sensor MC3210
ALS/Proximity N/A
To Next Page
