Hardware Specifications and Configurations 1-13
LAN Interface
Bluetooth Interface
Audio Amplifier IC
Item Specification
LAN Chipset No support on board LAN
LAN connector type N/A
LAN connector location N/A
Item Specification
Chipset AW-NH520
Data throughput
Bluetooth 2.1+Enhanced Data Rate (EDR) /
BT3.0+HX/BT4.0
Protocol TBD
Interface UART
Connector type I-PEX
Supported protocol TBD
Item Specification
Amplifier IC APA2010HAI-TRG
Feature
• Differential & Single-Ended input mode
• Output Power at 1%THD+N
• 2.4W, at VDD=5V, RL=4 ohm (WLCSP-9)
• Output Power at 10%THD+N
• 3.1W, at VDD=5V, RL=4 ohm (WLCSP-9)
• No external output L-C filter required
• The gain of the APA2010 has been set by the external
resistors (Rin)
• Speaker amplifier power supplies from 2.4V to 5.5V
• Low Shutdown Current IDD=1uA at VDD=5V
• High PSRR: 80dB at 217 Hz
• WLCSP1.5x1.5-9A package
• Fast Startup Time (4ms)
• Less External Components Required
• Thermal and Over-Current Protections
• Operating Voltage: 2.4V-5.5
• High Efficiency up to 90%
• Lead Free and Green Devices Available (RoHS
Compliant)
To Next Page
