6-4 FRU (Field Replaceable Unit) List
Table 6-1. Main Assembly Exploded Diagram
No. Description Acer P/N
1 ASSY LCD TOUCH MODULE 7.0" 6M.L15N2.001
2 BATTERY ADHESIVE 47.L15N2.003
3 CAMERA 1M+5M INCL. CAMERA FPC SPONGE 57.H99H2.001
4 CMOS GASKET 47.L15N2.002
5 CMOS RUBBER 47.L15N2.001
6 ANTENNA - GPS 50.L15N2.001
7 MIC SET 23.L15N2.001
8 ANTENNA - WLAN 50.L15N2.002
9
NC_Mainboard • Mainboard B1-A71 Acer Logo V1.0 LF
1GB RAM 8GB eMMC
NB.L1511.001
10 BATTERY
11 SPEAKER 23.L15N2.002
12 LOWER CASE - BLACK 60.L15N2.001
To Next Page
