ELECTRIC BICYCLE METER KT—LCD7C Product User Manual
- 13 -
interface, then the speed display column flashes. Press button (UP) or button
(DOWN) in order to set the maximum riding speed value. The default maximum riding
speed value was 25Km/h. When the speed of the electric vehicle exceeds the set value,
the motor will be stopped driving.
Setting interface of maximum trip speed
Under the setting maximum riding speed interface, if there’s no button operation
on the meter for more than 1 minute, and then the meter will automatically return to
display 1, and the original set values will be saved.
After finishing the maximum riding speed setting, Press button (SW) to save
the current set values and enter into the next setting.
○ Wheel Diameter
After finishing the maximum riding speed setting, enter the wheel diameter setting
interface, and then the wheel diameter display column flashes. Press button (UP) or
button (DOWN) to choose the corresponding wheel diameter specification to a
selected vehicle. The selection range of wheel diameter specifications are 16 species such
as 5,6,8,10,12,14,16,18,20,23,24,26,27.5,700C，28 and 29 inches.
Setting Interface of Wheel Diameter
