ELECTRIC BICYCLE METER KT—LCD7C Product User Manual
- 4 -
to achieve the best match of the three as motor, controller and meter to improve electronic
control performance of the electric motor. This manual covers installation, operation,
parameter setting of the meter and how to use it properly, which help you resolve the
problems appeared in practical use.
Outlook and Size
○ Meter Dimension
Meter Dimension
○ Main Material and Color
PC material is mainly used for KT-LCD7C meter and button box housing, and the
housing color is black.
○ Wiring Schematic
Installation Instruction
To Next Page
