ELECTRIC BICYCLE METER KT—LCD7C Product User Manual
- 19 -
○ C1 Power-Assist Sensor and Parameter Select Setting
Set C1 parameter first after entering C parameter setting environment, C1 parameter
column flashes.
C1 parameter setting interface
C1 is power-assist sensor and parameter select setting, its definition is shown in
following table. C1 setting ranges between 0-7, press button (UP) or button
(DOWN) for selection.
C1 parameter definition table：
After finishing C1 parameter setting, press button (SW) to save the current set
values and enter C2 parameter setting interface.
○ C2 Motor Phase Classification Coding Setting
Enter C2 parameter setting interface, C2 parameter column flashes.
To Next Page
