Tilt-A-Way HYJG
Trouble Shooting Guide
When calling Ideal Mfg., Inc. for trouble shooting help please note which lights on all of
the boards are on.
The following lights are normally on.
Logic Board.
Light P1 (red power light).
Light CAN1 (green communication to Motor Board, red communication lost to Motor
Board)
Light I3 (red stop circuit normally closed).
Motor Board.
Light DS2 (green power light).
PROBLEM DISPLAY LIGHTS
ON
SOLUTION
Gate closed and will not open
Blank None Power lost. Breaker turned off.
Check battery connections and
incoming ac power. Broken spring
or cable safety switch open.
Gate closed and will not open
Full Closed P1
CAN1
Stop circuit open. Check all external
stop push buttons.
Gate closed and will not open
Full Closed P1
CAN1
I3
I12
Opening safety edge active or
shorted. Check for obstruction or
replace if shorted.
Gate closed and will not open
Full Closed
Schedule Lockout
P1
CAN1
I3
Lockout Schedule active, Turn
lockout schedule off in menu.
Gate closed and will not open
Full Closed
Low Voltage Secure
P1
CAN1
I3
Battery voltage is low. Check
battery charge for proper operation
and battery connections.
Gate closed and will not open
Full Closed
Scheduled auto-open
P1
CAN1
I3
Check Lockout schedule for over
lapping times with Auto-open
schedule.
Gate closed and will not open
Full Closed
Service Lockout
P1
CAN1
I3
Service lockout for all maintenance
has been disabled. In menu Service
change to Controller Enabled.
Gate opened and will not close Blank None Power lost. Breaker turned off.
Check battery connections and
incoming ac power. Broken spring
or cable safety switch open.
Gate opened and will not close Full Open P1
CAN1
Stop circuit open. Check all external
stop push buttons.
Gate opened and will not close Full Open P1
CAN1
I3
I11
Closing safety edge active or
shorted. Check for obstruction or
replace if shorted.
