iDM iPUMP A 2-7 - Dimensions Outdoor Unit; Connections Outdoor Unit

(C) IDM ENERGIESYSTEME GMBH
3
.
D
escriptio
n
Installation instructions iPump A 2-7, 3-11
10
Description
Montage Heizungsseitig



Front view
Side view / left
Inlet side
Outlet side
3.5. Dimensions Outdoor unit










Refrigerant pipe connections
Ø10 mm and Ø12 mm
resp. Ø12 mm und Ø16 mm
Condensation
drain 1“
Outlet side
Inlet side
3.6. Connections Outdoor unit (View from below)
