Installation instructions iPump A 2-7, 3-11
17
description
Monta
g
e Heizun
g
sseiti
g
3.10. Filling quantity refrigerant
The iPump A 2-7 is pre-fi lled with refrigerant. Up to a distance of 6 m between indoor unit and outdoor unit no
refrigerant no additional needs to be refi lled. For pipe length more than 6 m, the following refrigerant quantities
must be refi lled.
3.11. Maximum heigth difference
If the height diff erence between the indoor unit and outdoor unit is lower than 5 m no oil elevation arc must be
installed before the inclination. In case of a higher height diff erence the installation must be done after 5 m. The
oil elevation arc must be installed by a certifi cated service technician. Whether the indoor unit or the outdoor
unit is higher, does not matter. The maximum height diff erence between indoor unit and outdoor unit is 10 m.
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0 2 4 6 8 10 12 14 16 18 20
ZĞͲĨŝůůƋƵĂŶƚŝƚLJ in [kg]
Wŝ
Ɖ
ĞůĞŶ
Ő
ƚŚŝŶŽŶĞĚŝƌĞĐƚŝŽŶ
[
m
]
ZĞĨƌŝŐĞƌĂŶƚƌĞͲĨŝůůƋƵĂŶƚŝƚLJ iPump A 2-7
WŝƉĞůĞŶŐƚŚŝŶŽŶĞĚŝƌĞĐƚŝŽŶ[m] ZĞĨƌŝŐĞƌĂŶƚƋƵĂŶƚŝƚLJ[kg] ZĞͲĨŝůůƋƵĂŶƚŝƚLJ [kg]
032Ϭ6
02Ϭ34Ϭ
01
04536551
07Ϭ39Ϭ02
max 5 m
<5 m
max 5 m
max 5 m
max 5 m
Height diff erence lower than 5 m
Height diff erence more than 5 m
Version 2Version 1
