iDM iPUMP A 2-7 - Default Chapter; Table of Contents

(C) IDM ENERGIESYSTEME GMBH
2
.
Installation instructions iPump A 2-7, 3-11
2
Contents
1. GENERAL INFORMATION 4
1.1. Standards and directives 4
1.2. Safety instructions 4
1.3. Storage 4
1.4. Installation room 4
1.5. Sound emission 5
1.6. Ice-covering outdoor unit 5
1.7. Installing additional components 5
1.8. Construction drying and screed heating 5
1.9. Cleaning 5
1.10. Servicing and maintenance 5
1.11. Service 5
1.12. Warranty and guarantee 5
1.13. Disposal 5
2. ACOUSTIC EVALUATION 6
3. D
ESCRIPTION 8
3.1. Intended use 8
3.2. Scope of delivery 8
3.3. Dimensions indoor unit 9
3.4. Connections indoor unit 9
3.5. Dimensions Outdoor unit 10
3.6. Connections Outdoor unit 10
3.7. Technical data 11
3.8. Performance data iPump A 2-7 acc. to EN 14511 13
3.9. Cooling data detailed iPump A 2-7 14
3.10. Filling quantity refrigerant 17
3.11. Maximum heigth difference 17
3.12. Linits of use 18
3.13. Performance data iPump A 3-11 acc. to EN 14511 20
3.14. Cooling data detailed iPump A 3-11 21
3.15. Filling quantity refrigerant 24
3.16. Maximum heigth difference 24
3.17. Limits of use 25
4. TRANSPORT 27
5. D
ISASSAMBLE THE IPUMP 28
5.1. Connecting the control unit 33
6. ASSEMBLY AND HYDRAULIC INSTALLATION 34
6.1. Assembly of the indoor unit 34
6.2. Replacement of the motor of the switching valve „Heating - hot water“ 36
6.3. Drinking water connection 37
6.4. Assembly of the outdoor unit 37
6.5. Installation variant for the outdoor unit 38
6.6. Place of installation 38
