D ADVANCED CONFIGURATION
Most of the OS310 configuration parameters are protected avoiding that for a mistake an essential
parameter is wrongly modified by the operator causing probe ill-behaviours. This section briefly
introduces the configuration parameters which can be configured when the probe access rights are
configured as SERVICE or ADMINISTRATOR. We suggest contacting IDRONAUT before modifying
any of these parameters.
D.1 OPERATING PARAMETERS
By means of the <CNOP> configuration command, available under the Configuration Menu, it is
possible to modify the below listed parameters:
Warm up timeout [s]: 5
Realtime data at startup ?: No
Identification code : 2
Serial number : 0000000
Standby between commands ?: Yes
Wake up from RS232 ?: Yes
Wait before shutdown [s]: 120
Wait valid command [s]: 60
Wait valid parameter [s]: 60
ER xxx messages ?: Yes
HEADER message : OCEAN SEVEN 310 -
Log Calibration ?: Yes
USB interface installed ?: No
BlueTooth installed ?: No
WIFI installed ?: No
Telemetry:0)No,1)QAM,2)FSK: 0
ComPort:(1)MAIN,(2)Aux#1,(3)Aux#3,(4)Rosette
Com. [1..4]:1
Speed(BPS):(3)2k4,(4)4k8,(5)7k2,(6)9k6,(7)19k2,(8)38k4,(9)57k6,(10)115k2
Baud Rate :10
Data bit:(0)7 bit, (1)8 bit
Data bit :1
Parity:(0)None,(1)Even,(2)Odd
Parity type:0
Stop bit:(0)1 bit, (1)2 bit
Stop bit :0
Flow Control:(0)None,(1)CTS/RTS,(2)DelayTx
Flow cnt :0
Emulate Digital VT100 ?: Yes
Com.protocol: 1)PTP : 1
N.data line between header: 24
N. of char per line : 132
D.2 DATA ACQUISITION PARAMETERS
By means of the <CNDA> configuration command, available under the Configuration Menu, it is
possible to modify the below listed parameters:
Conductivity range = Fresh water ? :No
Sampling rate [1..28]Hz: 28
Test battery ?: Yes
