IDS X64 Quick Programming Guide

IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
17
LOCATION 242
Keypad Zone Number (default = 0, i.e. Disabled)
[#] [INSTALLER CODE] [*] [2] [4] [2] [*] [KEYPAD NUMBER] [*] [ZONE NUMBER] [*]
Keypad number = 1 – 8
Start zone = 01 – 64
LOCATION 243
View Keypad ID
[#] [INSTALLER CODE] [*] [2] [4] [3] [*]
LOCATIONS 251 - 258
Keypad Options
[#] [INSTALLER CODE] [*] [LOCATION] [*] [BITMAP] [*]
Location = 251 – 258
LED
On / Off
Action
1
ON
The keypad will timeout back to its default partition after it has been used to
view another partition
OFF
The keypad will not timeout and will continue to show current partition
information
2
ON
Keypad sleep mode enabled
OFF
Keypad sleep mode disabled
3
ON
Enable Global Keypad Status
OFF
Disable Global Keypad Status
Default values are shaded
LOCATION 300
Global Reporting Code 1
[#] [INSTALLER CODE] [*] [3] [0] [0] [*] [SUB-LOCATION] [*] [REPORTING CODE] [*]
Sub-location = 1 – 8
Sub-location 1 is AC Fail
Sub-location 2 is AC Restore
Sub-location 3 is Low Battery Monitor Fail
Sub-location 4 is Low Battery Monitor Restore
Sub-location 5 is Auto Test
Sub-location 6 is Download
Sub-location 7 is Siren Monitor Fail
Sub-location 8 is Aux 12V Monitor Fail
Reporting code = 01 – FF, with 00 to disable
LOCATION 301
Global Reporting Code 2
[#] [INSTALLER CODE] [*] [3] [0] [1] [*] [SUB-LOCATION] [*] [REPORTING CODE] [*]
Sub-location = 1 – 8
Sub-location 1 is Reserved
Sub-location 2 is Bus-wired Peripheral Tamper

IDS X64 Specifications

General

Keypads	8
Stay/Away Arming	Yes
Tamper Protection	Yes
Operating System	Proprietary
Supported Protocols	Contact ID, SIA
Power Supply	16.5VAC
Backup Battery	12VDC 7Ah
Alerts	SMS
RAM	Unknown
