IDS X64

IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
32
LOCATIONS 581 - 588
Split Reporting Partitions 1-8
[#] [INSTALLER CODE] [*] [LOCATION] [*] [BITMAP] [*]
Location = 581 – 588
LED
On/Off
Action
LED
On/Off
Reporting Pair
1
ON
Enable duress reporting
9
ON
Telephone module 2
OFF
Disable duress reporting
OFF
Telephone module 1
2
ON
Enable keypad panic
reporting
10
ON
Telephone module 2
OFF
Disable keypad panic
reporting
OFF
Telephone module 1
3
ON
Enable fire reporting
11
ON
Telephone module 2
OFF
Disable fire reporting
OFF
Telephone module 1
4
ON
Enable medical reporting
12
ON
Telephone module 2
OFF
Disable medical reporting
OFF
Telephone module 1
5
ON
Enable keypad lockout
reporting
13
ON
Telephone module 2
OFF
Disable keypad lockout
reporting
OFF
Telephone module 1
6
ON
Reserved
14
ON
Reserved
OFF
Reserved
OFF
Reserved
7
ON
Enable armed without user
code reporting
15
ON
Telephone module 2
OFF
Disable armed without user
code reporting
OFF
Telephone module 1
8
ON
Reserved
16
ON
Reserved
OFF
Reserved
OFF
Reserved
Default values are shaded
