IDS X64

IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
29
LOCATION 572
Global Split Reporting 2
[#] [INSTALLER CODE] [*] [5] [7] [2] [*] [BITMAP] [*]
LED
On/Off
Action
LED
On/Off
Reporting Pair
1
ON
Enable bus-wired peripheral
tamper reporting
9
ON
Telephone module 2
OFF
Disable bus-wired peripheral
tamper reporting
OFF
Telephone module 1
2
ON
Enable bus-wired peripheral
fail reporting
10
ON
Telephone module 2
OFF
Disable bus-wired peripheral
fail reporting
OFF
Telephone module 1
3
ON
Enable bus-wired peripheral
low battery reporting *
11
ON
Telephone module 2
OFF
Disable bus-wired peripheral
low battery reporting *
OFF
Telephone module 1
4
ON
Enable AC restore reporting
12
ON
Telephone module 2
OFF
Disable AC restore reporting
OFF
Telephone module 1
5
ON
Enable communications
restore reporting**
13
ON
Telephone module 2
OFF
Disable communications
restore reporting **
OFF
Telephone module 1
6
ON
Enable telephone line
restore reporting
14
ON
Telephone module 2
OFF
Disable telephone line
restore reporting
OFF
Telephone module 1
7
ON
Enable siren restore
reporting **
15
ON
Telephone module 2
OFF
Disable siren restore
reporting **
OFF
Telephone module 1
8
ON
Enable panel low battery
restore reporting
16
ON
Telephone module 2
OFF
Disable panel low battery
restore reporting
OFF
Telephone module 1
Default values are shaded
* The reporting code is only supported by Contact ID, and thus will only be reported if Contact ID has
been selected.
* *The reporting code is only supported by Contact ID or SIA, and thus will not be reported if any other
format has been selected.
