IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
Individual Zone Type Setup (Zones 1 – 64)
[#] [INSTALLER CODE] [*] [LOCATION] [*] [ZONE NUMBER] [*] [ZONE TYPE] [*]
Location = 1 – 8
Zone number = 1 – 64
DISABLED
A zone violation of a Disabled zone is ignored by the control panel and will not be indicated on the
keypad.
PRIMARY ENTRY / EXIT ZONE
Violations of an Entry/Exit zone are ignored during the exit delay period of the arming procedure.
Violating an Entry/Exit zone when armed will initiate the entry delay. If a valid User Code is not entered
before the entry delay period expires, an alarm condition will be registered. Failure to exit through an
Entry/Exit zone after arming will cause the panel to Stay Arm.
This zone may also function as an Entry/Exit zone that is COMMON to two partitions. In such a case,
should a user violate this zone and then disarm his partition, the OTHER partition will re-arm after the
entry delay.
FOLLOWER ZONE
A violation of a Follower zone is ignored during the Entry/Exit delay period (this allows the user to
enter/exit via the Follower zone). A Follower zone will behave as an Instant zone if the panel is armed
and an Entry/Exit zone is not violated prior to violation of the Follower zone.
PANIC / PRIORITY ZONE
Regardless of whether the panel is armed or not, a violation of a Priority zone will cause the control
panel to register a panic condition. This zone type CANNOT be bypassed.
INSTANT ZONE
When the panel is armed the violation of an Instant zone will cause the control panel to register an
alarm condition.
ARM / DISARM ZONE
The violation of an Arm/Disarm zone will cause the panel to toggle between (away) armed and
disarmed. It is typical to connect a momentary key-switch, or non-latching remote control unit to this
zone.
SECONDARY ENTRY / EXIT ZONE
The Secondary Entry delay will be activated if this zone is violated when the panel is armed.
FIRE ZONE
Violation of a Fire Zone will cause the siren to sound regardless of whether the panel is armed or not.
The siren will sound intermittently (one second on, one second off). For correct operation, a
programmable output programmed as a fire detector power output must be used to control power to
the fire detector.
TAMPER ZONE
Violation of this zone will be reported to the base station regardless of whether the panel is armed or
disarmed. If the panel is armed, the siren will be activated.
24 HOUR ALARM ZONE
This works the same as a Panic zone – with the exception that it is able to be bypassed.
WARNING ZONE
When the panel is armed, violation of a Warning zone will cause the siren to beep. The violation is
logged in the event log but it is not reported to the base station. Warning zones may be included and
will be counted when used as part of the cross-zone
PUSH TO ARM ZONE
Violation
of
a
Push
to
A
rm
zone
during
the
exit
delay
will immediately
arm
the
panel.
OUTDOOR INSTANT ZONE
When the panel is armed the violation of an Outdoor Instant zone will cause the panel to register an
alarm condition.
