IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
28
Default values are shaded
LOCATION 571
Global Split Reporting 1
[#] [INSTALLER CODE] [*] [5] [7] [1] [*] [BITMAP] [*]
LED
On/Off
Action
LED
On/Off
Reporting Pair
1
ON
Enable AC fail reporting
9
ON
Telephone module 2
OFF
Disable AC fail reporting
OFF
Telephone module 1
2
ON
Enable communication fail
reporting *
10
ON
Telephone module 2
OFF
Disable communication fail
reporting *
OFF
Telephone module 1
3
ON
Enable telephone line
tamper reporting
11
ON
Telephone module 2
OFF
Disable telephone line
tamper reporting
OFF
Telephone module 1
4
ON
Enable siren fail reporting
12
ON
Telephone module 2
OFF
Disable siren fail reporting
OFF
Telephone module 1
5
ON
Enable panel low battery fail
reporting
13
ON
Telephone module 2
OFF
Disable panel low battery fail
reporting
OFF
Telephone module 1
6
ON
Enable aux 12V fuse fail
reporting
14
ON
Telephone module 2
OFF
Disable aux 12V fuse fail
reporting
OFF
Telephone module 1
7
ON
Reserved
15
ON
Reserved
OFF
Reserved
OFF
Reserved
8
ON
Enable box tamper reporting
16
ON
Telephone module 2
OFF
Disable box tamper
reporting
OFF
Telephone module 1
Default values are shaded
* The reporting code is only supported by Contact ID or SIA, and thus will not be reported if any other
format has been selected.
