IDS X64

IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
27
LED
ON Days of the Week
LED
OFF Days of the Week
1
Monday
9
Monday
2
Tuesday
10
Tuesday
3
Wednesday
11
Wednesday
4
Thursday
12
Thursday
5
Friday
13
Friday
6
Saturday
14
Saturday
7
Sunday
15
Sunday
All OFF
(Arm Day Disabled)
All OFF
(Disarm Day Disabled)
LOCATIONS 501 – 564
Split Reporting Zones 1 - 64
[#] [INSTALLER CODE] [*] [LOCATION] [*] [BITMAP] [*]
Location = 501 – 564
LED
On/Off
Action
LED
On/Off
Reporting Pair
1
ON
Enable zone alarm reporting
9
ON
Telephone module 2
OFF
Disable zone alarm reporting
OFF
Telephone module 1
2
ON
Enable zone alarm restore
reporting
10
ON
Telephone module 2
OFF
Disable zone alarm restore
reporting
OFF
Telephone module 1
3
ON
Enable zone bypass
reporting
11
ON
Telephone module 2
OFF
Disable zone bypass
reporting
OFF
Telephone module 1
4
ON
Enable zone force arm
reporting
12
ON
Telephone module 2
OFF
Disable zone force arm
reporting
OFF
Telephone module 1
5
ON
Enable zone tamper
reporting
13
ON
Telephone module 2
OFF
Disable zone tamper
reporting
OFF
Telephone module 1
6
ON
Enable zone tamper restore
reporting
14
ON
Telephone module 2
OFF
Disable zone tamper restore
reporting
OFF
Telephone module 1
7
ON
Enable zone swinger
shutdown reporting
15
ON
Telephone module 2
OFF
Disable zone swinger
shutdown reporting
OFF
Telephone module 1
8
ON
Enable zone swinger
shutdown restore reporting
16
ON
Telephone module 2
OFF
Disable zone swinger
shutdown restore reporting
OFF
Telephone module 1
