IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
31
LOCATION 574
Global Split Reporting 4
[#] [INSTALLER CODE] [*] [5] [7] [4] [*] [BITMAP] [*]
LED
On/Off
Action
LED
On/Off
Reporting Pair
1
ON
Enable download reporting
9
ON
Telephone module 2
OFF
Disable download reporting
OFF
Telephone module 1
2
ON
Reserved
10
ON
Reserved
OFF
Reserved
OFF
Reserved
3
ON
Reserved
11
ON
Reserved
OFF
Reserved
OFF
Reserved
4
ON
Reserved
12
ON
Reserved
OFF
Reserved
OFF
Reserved
5
ON
Reserved
13
ON
Reserved
OFF
Reserved
OFF
Reserved
6
ON
Reserved
14
ON
Reserved
OFF
Reserved
OFF
Reserved
7
ON
Reserved
15
ON
Reserved
OFF
Reserved
OFF
Reserved
8
ON
Reserved
16
ON
Reserved
OFF
Reserved
OFF
Reserved
Default values are shaded
