IDS X64 Quick Programming Guide

IDS X64 Quick Programming Guide 700-398-03A Issued August 2010
7
LOCATION 16
Trouble Display Enable
[#] [INSTALLER CODE] [*] [1] [6] [*] [BITMAP] [*]
LED
On / Off
Action
1
ON
Enable AC fail trouble display
OFF
Disable AC fail trouble display
2
ON
Enable reporting communications fail trouble display
OFF
Disable reporting c ommunications fail trouble display
3
ON
Enable tele phone line monitoring trouble display
OFF
Disable tele phone monitoring line trouble display
4
ON
Enable siren monitoring trouble display
OFF
Disable siren monitoring trouble display
5
ON
Enable low battery monitoring trouble display
OFF
Disable low battery monitoring trouble display
6
ON
Enable Aux. 12V monitoring trouble display
OFF
Disable Aux. 12V monitoring trouble display
7
ON
Enable engineer's reset trouble display
OFF
Disable engineer’s reset trouble display
8
ON
Enable box tamper trouble display
OFF
Disable box tamper trouble display
9
ON
Enable bus-wired peripheral tamper trouble display
OFF
Disable bus-wired peripheral tamper trouble display
10
ON
Enable bus-wired peripheral fail trouble display
OFF
Disable bus-wired peripheral fail trouble display
11
ON
Enable bus-wired peripheral low power/ battery trouble display
OFF
Disable bus-wired peripheral low power/ battery trouble display
12
ON
Enable EEPROM trouble display
OFF
Disable EEPROM trouble display
Default values are shaded
LOCATION 17
Siren Time Out Period (default = 0200)
[#] [INSTALLER CODE] [*] [1] [7] [*] [MMSS] [*]
MMSS = 00m01s – 59m59s
LOCATION 18
Siren Delay (default = 0200)
[#] [INSTALLER CODE] [*] [1] [8] [*] [MMSS] [*]
MMSS = 00m01s – 59m59s
LOCATION 20
Keypad Lockout Count (default = 4)
[#] [INSTALLER CODE] [*] [2] [0] [*] [KEYPAD LOCKOUT COUNT] [*]
Lockout count = 2 – 16
