9.3 Reader Operations
The demo software can be used to display the card data and send reader commands. To
view the card data on screen, place the cursor in the “manual command/ reader output”
text box and swipe the card. To send a reader command, type the appropriate command
in the text box and press the “Send Command” button.
General Setting
Provide options such as reader default settings, firmware version, beeper options, and
buffered mode options. For USB demo software, there are options to set the reader to
USB KB or USB HID mode.
MSR Security
The security is enabled by selecting TDES or AES. Once the encryption is enabled the
reader cannot be changed back to non-encrypted mode.
Port/ Settings
RS232 interface: select Com port and open/ close port.
USB KB interface: set KB polling interval and select language settings
Help
Provides version information of the demo software.
