SecureMag User Manual
10.3 DUKPT Level 3 Data Output Original Format
For ISO cards, both masked clear and encrypted data are sent, no clear data will
be sent.
For other cards, only clear data is sent.
A card swipe returns the following data:
Card data is sent out in format of
<STX><LenL><LenH><Card Data><CheckLRC><CheckSum><ETX>
<STX> = 02h, <ETX> = 03h
<LenL><LenH> is a two byte length of <Card Data>.
<CheckLRC> is a one byte Exclusive-OR sum calculated for all <Card Data>.
<CheckSum> is a one byte Sum value calculated for all <Card data>.
<Card Data> card data format is shown below.
ISO/ABA Data Output Format:
 card encoding type (0: ISO/ABA, 4: for Raw Mode)
 track status (bit 0,1,2:T1,2,3 decode, bit
3,4,5:T1,2,3 sampling)
 track 1 unencrypted length (1 byte, 0 for no track1 data)
 track 2 unencrypted length (1 byte, 0 for no track2 data)
 track 3 unencrypted length (1 byte, 0 for no track3 data)
 track 1 masked (Omitted if in Raw mode)
 track 2 masked (Omitted if in Raw mode)
 track 3 data (Omitted if in Raw mode)
 track 1,2 encrypted (AES/TDES encrypted data)
 track 1 hashed (20 bytes SHA1-Xor)
 track 2 hashed (20 bytes SHA1-Xor)
 DUKPT serial number (10 bytes)
Non ISO/ABA Data Output Format
 card encoding type (1: AAMVA, 3: Others)
 track status (bit 0,1,2:T1,2,3 decode, bit
3,4,5:T1,2,3 sampling)
 track 1 unencrypted data length (1 byte, 0 for no track1 data)
 track 2 unencrypted data length (1 byte, 0 for no track2 data)
 track 3 unencrypted data length (1 byte, 0 for no track3 data)
 track 1 data
 track 2 data
 track 3 data
