SecureMag User Manual
81 01
Input Constant
95 05
Report Count
75 01
Report Size
05 08
Usage Page (LED)
19 01
Usage Minimum
29 05
Usage maximum
91 02
Output(Data Variable Absolute)
95 01
Report Count
75 03
Report Size
91 01
Output (Constant)
95 06
Report Count
75 08
Report Size
15 00
Logical Minimum
25 66
Logical Maximum (102)
05 07
Usage Page (key Code)
19 00
Usage Minimum
29 66
Usage Maximum (102)
81 00
Input(Data, Array)
06 2D
FF
Usage Page (ID TECH)
95 01
Report Count
26 FF
00
Logical maximum (255)
15 01
Logical Minimum
75 08
Report Size (8)
09 20
Usage (Setup data byte)
95 08
Report Count (8)
B2 02
01
Feature (Data Var, Abs)
C0
End Collection
10.2 Level 1 and level 2 POS Mode Data Output Format
In POS mode use the special envelope to send out card data, envelope is in the
following format:
[Right Shift, Left Shift, Right Ctrl, Left Ctrl,] Read Error, Track x ID; Track x
Error; Track x Data Length; Track x Data; Card Track x LEC code; Track x
data LRC.
Reader will send out card data in Alt mode if its ASCII code less than H’20’.
Byte NO.
Name
0
Right Shift
