SecureMag User Manual
1
Left Shift
2
Right Ctrl
3
Left Ctrl
4
Read Error 1
5
Read Error 2
6
Track x ID
7
Track x Error
8
Track x Length 1
9
Track x Length 2
10
Track Data (no extra
Track ID for raw data)
…
10 + Track len -1
Card Track x LRC
10 + Track len
Track x LRC
10 + Track len +1
0x0D
10 + Track len + 2
Track x ID
….
Repeat Track
The data format is independent with MSR setting. No Track x data if track x
sampling data does not exist.
OPOS header:
Only HID KB interface has [Right Shift, Left Shift, Right Ctrl, Left Ctrl] under
POS mode.
Read Error:
Read Error 1 byte bits:
MB LB
0
B6
B5
B4
B3
B2
B1
B0
B0 1: Track 1 sampling data exists (0: Track 1 sampling data does not exist)
B1 1: Track 2 sampling data exists (0: Track 2 sampling data does not exist)
B2 1: Track 3 sampling data exists (0: Track 3 sampling data does not exist)
B3 1: Track 1 decode success (0: Track 1 decode fail)
B4 1: Track 2 decode success (0: Track 2 decode fail)
B5 1: Track 3 decode success (0: Track 3 decode fail)
B6 0: if b0 to b5 are all 1, otherwise 1 (make it printable)
Read Error byte 2:
MB LB
0
1
B12
B11
B10
B9
B8
B7
B7 1: Track 4 sampling data exists (0: Track 4 sampling data does not exist)
B8 1: Track 4 JIS II decode success (0: Track4 JIS II decode fail)
B9, B10, B11
