SecureMag User Manual
Appendix A Setting Configuration Parameters and Values
Following is a table of default setting and available settings (value within parentheses)
for each function ID.
Function ID
Hex
Description
Default
Setting
Description
HTypeID
10
Terminal Type
'0'
(‘0’~’2’,'4'~'6')
PC/AT, Scan Code Set 2, 1,
3, PC/AT with external
Keyboard and PC/AT
without External Keyboard
k
r
BeepID
11
Beep Setting
Beep frequency
and duration
‘2’ (‘0’~’4’)
‘0’ no beep; ‘1’ low long; ‘2’
high long; ‘3’ high short;
low short;
ChaDelayID
12
Character
Delay
‘0’ (‘0’~’5’)
‘6’
2 ms inter-character delay
‘6 for 0 mS delay
k
TrackSelectID
13
Track Selection
‘0’ (‘0’~’9’)
0x30 – Any
Track
0x31 – Track 1
Only
0x32 – Track 2
Only
0x33 – Track 1
& Track 2
0x34 – Track 3
Only
0x35 – Track 1
& Track 3
0x36 – Track 2
& Track 3
0x37 – All
Three Tracks
0x38 – Track 1
Or Track 2
0x39 – Track 2
Or Track 3
Any Track 0-any; 1-7—bit 1
tk1, bit 2 tk2; bit 3 tk3. ‘8’—
tk1-2; ‘9’ tk2-3
If a track is not selected in a
secure reader that track is
not processed or recognized.
PollingInterval
ID
14
Polling Interval
1 (1 ~ 255)
USB HID Polling Interval
u
DataFmtID
15
Data Output
Format
‘0’ (‘0’~’2’)
‘0’-ID TECH Format; ‘1’-
UIC; ‘2’-Mag-Tek Format
FmtOptionID
16
UIC, Mag-Tek
H’59’
Refer to MiniMag RS232
User’s Manual
TrackSepID
17
Track
0x0D=CR/Ente
CR for RS232, Enter for KB
