Report Descriptor: (USB KB Interface)
Value
Description
05 01
Usage Page (Generic Desktop)
09 06
Usage(Keyboard)
A1 01
Collection (Application)
05 07
Usage Page (Key Codes)
19 E0
Usage Minimum
29 E7
Usage Maximum
15 00
Logical Minimum
25 01
Logical Maximum
75 01
Report Size
95 08
Report Count
81 02
Input (Data,Variable,Absolute)
95 01
Report Count (1)
75 08
Report Size
26 FF
00
Logical Maximum
75 08
Report Size
09 20
Usage (Tk1 Decode Status)
09 21
Usage (Tk2 Decode Status)
09 22
Usage (Tk3 Decode Status)
09 28
Usage (Tk1 Data Length)
09 29
Usage (Tk2 Data Length)
09 2A
Usage (Tk3 Data Length)
09 38
Usage (Card Encode Type)
95 07
Report Count
81 02
Input (Data,Var,Abs,Bit Field)
09 30
Usage (Total Sending Length)
95 02
Report Count (2)
82 02
01
Input (Data, Var, Abs, Bit Field)
09 31
Usage (Output Data)
96 27
02
Report Count (HIDSIZE = 551+9=560 )
82 02
01
Input (Data, Var, Abs, Bit Field)
09 20
Usage (Command Message)
95 08
Report Count
B2 02
01
Feature (Data,Var, Abs, Buffered Bytes)
C0
End Collection
