When sending the authentication request, the user also needs to specify a time limit
for the reader to wait for the activation challenge reply command. The minimum
timeout duration required is 120 seconds. If the specified time is less than the
minimum, 120 seconds would be used for timeout duration. The maximum time
allowed is 3600 seconds (one hour). If the reader times out while waiting for the
activation challenge reply, the authentication failed.
Device Response
When authentication mode is requested, the device responds with two challenges:
Challenge 1 and challenge 2. The challenges are encrypted using the current DUKPT
key exclusive- or’ed with <F0F0 F0F0 F0F0 F0F0 F0F0 F0F0 F0F0 F0F0>.
The decrypted challenge 1 contains 6 bytes of random number followed by the last
two bytes of KSN. The two bytes of KSN may be compared with the last two bytes of
the clear text KSN sent in the message to authenticate the reader. The user should
complete the Activate Authentication sequence using Activation Challenge Reply
command.
Command Structure
Host -> Device:
<STX><R><80h><02h><Pre-Authentication Time Limit><ETX><LRC>
Device -> Host:
<ACK><STX><Device Response Data><ETX><LRC> (success)
<NAK> (fail)
Pre-Authentication Time Limit: 2 bytes of time in seconds
Device Response Data: 26 bytes data, consists of <Current Key Serial Number>
<Challenge 1> <Challenge 2>
Current Key Serial Number: 10 bytes data with Initial Key Serial Number in the
leftmost 59 bits and Encryption Counter in the rightmost 21 bits.
Challenge 1: 8 bytes challenge used to activate authentication. Encrypted using the
key derived from the current DUKPT key.
Challenge 2: 8 bytes challenge used to deactivate authentication. Encrypted using the
key derived from the current DUKPT key.
Activation Challenge Reply Command
This command serves as the second part of an Activate Authentication sequence. The
host sends the first 6 bytes of Challenge 1 from the response of Activate
Authenticated Mode command, two bytes of Authenticated mode timeout duration,
and eight bytes Session ID encrypted with the result of current DUKPT Key
exclusive- or’ed with <3C3C 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C>.
