Lrc option
don’t send track LRC
T28BStartID
72
JIS T12 SS/ES
0x00 or 0x7F
0 unless keyboard version
then 0x7F
i
T38BStartID
73
JIS T3 SS/ES
0x00 or 0x7F
0 unless keyboard version
then 0x7F
i
SPISettingID
75
'0'
p
EquipFwID
77
feature option
setting
any
Factory Reader firmware
configuration setting
r
n
SyncCheckID
7B
check for track
sync bits-can
allow poorly
encoded cards
to be read
‘0’ (‘0’-2’)
check leading & trailing
sync bits ‘0’ 13 bits; ‘1’ 13
bits, but allow if valid
through track LRC; '2' 9 bits
ABA; 13 bits IATA; 16 bits
JIS
MagTSecureL
vlID
7D
‘1’ (‘0’-‘3’)
p
SecurityLevelI
D
7E
Reader’s
encryption
level
‘1’ or ‘3’ (‘0’-
‘4’)
‘1’ no encryption; ‘2’ key
loaded; ‘3 encrypted reader;
‘0’ DUKPT exhausted; ‘4’
authentication required
n
r
MagTCryptID
7F
'1'(‘0’-‘3’)
p
EncryptOptID
84
encryption
options,
enhanced only
8 encrypt trk 3
if card type 0;
(0-F)
bit 0 encrypt trk1; bit 1
encrypt trk2; bit 3 encrypt
trk3; bit 4 encrypt trk3 if
card type 0
EncryptStrID
85
encrypt
structure
'0'
‘0’ original; ‘1’ enhanced
MaskOptID
86
clear / mask
data options
7
bit 0 send clear/mask trk1 bit
1 send clear/mask trk2 bit 2
send clear/mask trk3
PrefixID
D2
Preamble
0 (any 15)
No Preamble, 15 char max
1
PostfixID
D3
Postamble
0 (any 15)
No Postamble, 15 char max
AddedFieldID
FA
Data Edit
Added field
0
See Data Edit documentation
i
SearchCmdID
FB
Data Edit
Search cmd
0
See Data Edit documentation
i
SendCmdID
FC
Data Edit send
cmd
0
See Data Edit documentation
i
SendCmd2ID
FD
Data Edit send
cmd 2
0
See Data Edit documentation
i
1
PrefixID and PostFixID are ignored on encrypted transaction unless the reader is a keyboard
reader, then they are supported so that the host can recognize the reader’s output.
