101-091 16
FGR006 – Version 3.0
–
FGR006 FINGERPRINT & PROXIMITY READER
6.2 Reader Mode
6.2.1 A Reader Mode Function.
In reader mode cards and fingerprints are read for access authorization.
If your fingerprint is authorized then the system will transmit the card ID.
If your fingerprint is not authorized then error signal output.
For reader mode situation refer to the "7.Operation Indication of Reader / Register"
of manual.
6.2.2 Authorization procedure.
When in program mode (i.e. after the Master card has been presented), present a proximity card to
the FGR006
If your card ID is registered then fingerprint scanner will light on.
If your card ID is not registered then FGR006 will make 2 beep sounds and return to reader mode.
Put your finger on the fingerprint scanner for authorization.
If your fingerprint is authorized then FGR006 will turn on the lens led (upper light) and make a
beep sound for a second and will send your card ID to the access controller.
If your fingerprint is not authorized then FGR006 will make 2 beep sounds
and generate finger error signal for 500ms of low active pulse. (Only available when your
FGR006 is set to 26bit Wiegand output)
6.3 Registration Mode
6.3.1 A Registration Mode Function
To access registration mode into a FGR006 you must first present the Master card.
In registration mode you can add or delete cards.
It deletes the card when user card has already been registered. (Beeps 4 times)
It registers the card when user card is not registered. (Beeps 3 times)
