101-091 5
FGR006 – Version 3.0
–
FGR006 FINGERPRINT & PROXIMITY READER
Colour Light and Dark Grey
Operating Environment -15˚~+40˚ (-5˚~ +104˚), 0~90% Humidity
Overall Size (WxHxD) 66x129x51mm (2.6"x5.1"x2.0")
Weight 230g (0.5lb)
3. Product Overview
3.1. FUNCTION
The FGR006 is finger reader with integrated proximity reader and registration terminal.
[Registration Mode]
The registration mode registers (or deletes) user cards.
[Reader Mode]
If your fingerprint is authorized then FGR006 will send your card ID to the access controller.
[Master Card]
A master card is used to change modes from Registration to reader modes.
[A Card Number Output Form]
If your fingerprint is authorized then output becomes the card number to 26bit Wiegand or ABA
Track II according to an output type.
[An Error Signal Output]
If your fingerprint is not authorized then FGR006 will generate finger error signal for 500ms of
low active pulse. (Only available when your FG006 is set to 26bit Wiegand output)
This signal is open collector.
