101-091 4
FGR006 – Version 3.0
–
FGR006 FINGERPRINT & PROXIMITY READER
2. Introduction
2.1 Identifying Supplied Parts
Please unpack and check the contents of the box.
Main Unit Bezel User’s Manual RS232 Serial line
(OPTION)
2.2 About NESS - IDTECK FGR006/FGR006EX
The NESS - IDTECK FGR006 is a Biometrics and Proximity Reader, which is compatible to existing
proximity readers. FGR006 can be connected to any existing access control panel and you will have personal
authorization by one’s fingerprint to avoid any access from un-authorized person. FGR006 has built-in
proximity reader and fingerprint module so that the access is only allowed when the personal ID and
fingerprint are authorized. Its modern design gives you an easy installation (just replace existing reader) to
metal door frame (mullion) or to any flat wall surface. FGR006 ensures you a successful operation where you
want biometrics access control. FGR006 has three LED of red, green and lens (upper right), inside beeper
sound to guarantee you an accurate and reliable access control.
2.3 Specification
CPU 32bit, dual 8bit Microprocessor
Memory Program Memory: 64KB EEPROM
Power DC 12V/350mA max
Card Holders 720 (optional 2,000/4,5000)
Reader Port (FGR006EX only) 1 Extra port
Reader Data Format 26bit Wiegand, 8bit burst Format for keypad reader
Output Format 26bit Wiegand, ABA Track II Magstripe format (Caution: Card
Present signal is Open Collector)
Communication port RS232, RS485, RS422 (default, up to 255ch) selectable
4800,9600(Default), 19200, 38400, 57600, 115200bps
communication speed
LED Control Input Low active, maximum 20mA current drain
Beeper Control Input Low active, maximum 20mA current drain
Tamper Switch Low active
LED/Beeper Three LEDs / Piezo Buzzer
