FGR006 – Version 3.0
IDTeck
–
FGR006 FINGERPRINT & PROXIMITY READER
RS485 COMMUNICATION PORT
RS485-A 485A Grey
RS485-B 485B Yellow
RS422 COMMUNICATION PORT Î DEFAULT
RS422 TX+ TX+ Grey
RS422 TX- TX- Yellow
RS422 RX+ RX+ Brown
RS422 RX- RX- Blue
TAMPER SWITCH
Tamper Switch TAMPER Purple
EXTERNAL READER PORT (FGR006EX Only)
Wiegand Data-0 IN_DATA0 Pink
Wiegand Data-1 IN_DATA1 Cyan
