Page #21 background imageLoading...
Page #21 background image
21
ACCURA9/9L INSTRUCTION MANUAL
FUNCTIONS
Exchanging barrels
Press
CLR RESET
key when changed barrels.
The shot pressure and vacuum pressure return to the initial setting values. The shot counter is reset to ‘0’.
Dispensing
The shot keeps going only while pressing the
/OFF
key. When release
/OFF
key, the actual shot
period is shown at
St.
The vacuum compensation and the level compensation work when
Bot_Level and Bot_Level
are set
ON’
in the D.SAMP screen.
Remote Mode
RemoteModeScreen
***SteadyShotEXT
Ch00St00.000
Sp100.0Sc000300
CmLEVC
Enter into Remote Mode with
Remote key
.
Dispensing is operated by signal from external input in the
remote mode.
In order to meet the individual user’s requirements, the
foot switch (
FSW
,
EXIT
I/O(EXT
and
S232C(RS2
can be used for dispensing.
Each time when press the
REMOTE key
,
FSWEXT and RS2
will appear.
When using only foot switch, it is switchable from LCD panel by pressing
SHIFT
+REMOTE key
Refer to Art. 10. Remote Mode for the detail of remote mode.
Completion of STEADY Mode
Press the
H+MODE key
except when entering the remote mode to finish the STEADY Mode.
