５８
ACCURA9/9L INSTRUCTION MANUAL
11.2 Connect the Input and Output Signal
Ｉ／Ｏ Port Signal(input)
USER LOGIC
USER SOURCE
+8VDC〜+40VDC
+COM
IN PUT
ACCURA 9
GND
15,16,17,
GND
REGULATOR
+5V
+5V(INSULATION)
GND (ACCURA 9)
+5V(ACCURA 9)
1,2,20,21
GND (ACCURA 9)
+5V(ACCURA 9)
IN PUT
SW1
ISO
EXT
31,32,33
(INSULATION)
SHIELD
F.G
