ACCURA9/9L INSTRUCTION MANUAL
4.2 Rear Panel of controller
④
I/OPORT2
I/OPORT1
⑥
FUSE
⑤
ACIN
RS232C
③
SHOTCON.
⑦
GND
⑧
②
EJECTOR
①
AIRIN
Components Names
① ．．．
Air Import Port
② ．．．
Exhaust silencer
③ ．．．
Control connector
④ ．．．
Outer input/output connector
⑤ ．．．
Power source connector
⑥ ．．．
Fuse
⑦ ．．．
Ground
⑧ ．．．
RS232C connector
