ACCURA9/9L INSTRUCTION MANUAL
SHOT END (I/O PORT2 6PIN)
6PIN OUTPUT CONDITION
０
Output while dispensing.
１
Output while not dispensing.
Counter (I/O PORT2 25PIN)
25PIN OUTPUT CONDITION
０
Output while dispensing.
１
Output while not dispensing.
Alarm/Error signal
(I/O PORT2 22PIN)
22PIN OUTPUT CONDITION
０
Output if no errors occur in the dispenser controller.
１
Output if any error occurs in the dispenser controller.
Reset by ‘Alarm-reset’ of control signal, if the signal turns
‘1’.
Empty Alarm Signal (I/O PORT2 3PIN)
3PIN OUTPUT CONDITION
０
Output if Empty Alarm or Count-up function does not occur.
１
Output if Empty Alarm or Count-up function works. Output on
the Alarm/Error signal if this signal turns ‘1’ with an exception of
follows: If select ‘continue to dispense’ on Empty Alarm setting,
this signal isn‘t shown on the display. On exchanging barrels, it is
reset by the resetting control signal.
.
