prox.pad Plus IR Access System Installer Guide
Programming Options Chart
The following chart contains a list of programming commands available in the prox.pad Plus IR. When programming users, the term
user location refers to the place in the units memory that the user is stored.
Action Desired Press Details
Enter Program Mode 99 # (Master Code) * Yellow LED blinks slowly
Change Master Code
1 # (new code) * (repeat code) *
Ex: 1 # 4321 * 4321 *
Code-only operation
Program Supervisor code 2 # (new code) * (repeat code) *
Assign Outputs 10 # output # relay/audio alert # **
Outputs Relay/Audio Alert
0 – Disable Output 1 – Relay 1 (Main)
1 – Lock Output 2 – Relay 2 (Aux)
2 – Alarm Shunt 5 – Audio Alert #1 (¼ sec on, ¼ sec off)
3 – Door Ajar 6 – Audio Alert #2 (beep every 2 sec)
4 – Forced Door
Set main relay time 11 # time # 0 # **
Time =1-99 seconds (default = 5
seconds)
Set/clear standard option 30 # option # s/c # ** See Chart below
Option Set Clear
0 – Audio Keypress Feedback 0 = Disabled 1 = Enabled
1 – Visual Keypress Feedback 0 = Disabled 1 = Enabled
2 – Auto Entry Enable 0 = Disabled 1 = Enabled
3 – Code and Card Required for
Program Mode
0 = Disabled 1 = Enabled
5 – User Lockout Enable 0 = Disabled 1 = Enabled
7 – Internal REX Switch 0 = Disabled 1 = Enabled
9 – Time Zone Select 0 = Disabled 1 = Enabled
11 – Auto-Unlock Select 0 = Disabled 1 = Enabled
12 – First-In Auto-Unlock 0 = Disabled 1 = Enabled
13 – Daylight Saving Time 0 = Disabled 1 = Enabled
15 – Daylight Saving Time Format 0 = US 1 = European
16 – Timed Anti-Passback 0 = Disabled 1 = Enabled
Page 28 of 32 Document # 6105681, Rev 1.1, D2a
