prox.pad Plus IR Access System Installer Guide
prox.pad Plus IR Specifications
Table 2: prox.pad Plus IR Specifications
Electrical
Power Supply/Current Requirements 12-24 VDC, linear filtered and regulated power supply; 150mA
Wiring
Remote Antenna Cable (if installing in a
secured configuration)
[ALPHA 1294C (22AWG) 4-conductor, stranded and shielded]
Power Supply Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Lock Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Monitor Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
REX Cable
[ALPHA 2421C 18 AWG or ALPHA 1292C 22 AWG, 2-conductor,
stranded and shielded] (if using remote switch)
Mechanical
Height 5.25 in (13.3 cm)
Width 2.75 in (7 cm)
Depth 1.625 in (4.13 cm)
Relay Outputs
Main Relay Form C (switches up to 2A)
Program for either timed (1-99 sec) or toggle
Aux Relay Form C (switches up to 1A)
One of three functions can be programmed: Alarm Shunt Relay,
Forced Door Relay, or Propped Door Relay
Monitor Inputs
Door Position Switch Normally Closed, Dry Contact
Other Outputs
Infrared Output For communicating to the LS Link PDA Software for programming
Sounder 4000 Hz, defeatable
Bi-Color LED Red/Green
Yellow LED
Compatible Proximity Cards (All HID cards up to 40 bits, including the following)
Prox Card II, IsoProx II, DuoProx II, Proxkey FOB
Unit Capacity
Users 2000 Maximum (each user can have a card, PIN or both)
Transactions
2000 Maximum (includes event number, time, date, and user
number if applicable)
Environmental
Operating Environment Indoor or Outdoor
Operating Temperature -31° to 150° F (-35° to 66° C)
Operating Humidity 5% to 95% relative humidity, non-condensing
Page 6 of 32 Document # 6105681, Rev 1.1, D2a
