IEMCA MASTER 880 MP-E - Page 26

GB
2 - TECHNICAL INFORMATION MASTER 880MP E-volution
2 - Pag. 16 / 19
Table 6. Guide channel, bar pusher, bar and tube diameters
Bar diameter
Model
Guide channel
diameter (mm)
Bar pusher
diameter
(mm)
Minimum Maximum
Tube
diameter
(mm) (*)
21 20 8 18 20
26 25 8 23 25
33 (**) 32 10 29 31
36 35 10 32 35
38 37 11 35 37
43 42 12 39 42
46 45 15 42 45
52 51 18 47 51
57 56 22 52 56
61 (**) 60 30 56 60
66 65 38 61 65
69 68 48 63 68
71 70 48 65 70
73 72 50 67 72
76 75 50 70 75
81 80 52 75 80
MASTER 880 MP
Evolution
86 (**) 85 55 80 80
(*) Valid also for prepared bars or normal bars machined with front remnant ejection.
(**) Recommended guide according to max lathe bar passage.
Example: ø85 max bar passage - GUIDES 86-61-33.
Example: ø80 max bar passage - GUIDES 81-61-33.
Example: ø75 max bar passage - GUIDES 76-61-33.
