2 - TECHNICAL INFORMATION MASTER 880MP E-volution
GB
2 - Pag. 15 / 19
Table 5. Working axis height
Model Screws position X (mm)
High bedframe
X (mm)
Low bedframe
2 1215÷1249 900÷934
3 1250÷1284 935÷969
4 1285÷1319 970÷1004
5 1320÷1354 1005÷1039
6 1355÷1389 1040÷1074
7 1390÷1424 1075÷1109
8 1425÷1459 1110÷1144
9 1460÷1494 1145÷1179
MASTER 880 P
MASTER 880 F
10 1495÷1535 1180÷1220
