4 - HANDLING AND INSTALLATION MASTER 880MP E-volution
GB
4 - Pag. 5 / 17
4.3 INSTALLATION AREA - CHARACTERISTICS
The floor should be stable and levelled to guarantee good fastening to the ground.
Provide an area of suitable dimensions according to the type of feeder use.
The area: A (work area, bar feeding area ,remnant discharge area) should be properly delimited
to prevent collisions between the operator and any handling equipment or transport vehicles
travelling near the bar feeder.
The selected bar feeder setting should be suitably lit and provided with an electric power and
air outlets.
During operation, the feeder will release small amount of oil vapors. Make sure that the
premises where the feeder is installed are suitably ventilated.
The feeder has not been designed and built for use in an explosive atmosphere.
Model Version A (mm)
33 4000
38 4500
MASTER 880 MP
Evolution
43 5000
