5 - ADJUSTMENTS AND SETTING-UP MASTER 880MP E-volution
5 - Pag. 10 / 14
CAUTION-PRECAUTION :
At every collet change (modell 381p, 381p..011,
381p..021 e 386p) it is necessary to install the
grub screw H and the counter screw L.
CAUTION:
the collet outside diameter should be at
least 0.5 mm smaller than the bar-
pusher outside diameter.
• Install the collet in the bar-pusher and make
sure that the rings are riveted in their special
recesses to prevent accidental collet
unscrewing from its connection.
• Install a suitable 1st feeding carriage (B) for the
new diameter, followed by the block (A).
